Zn Series Concrete Vibrator Shaft/ Wire-Netted Rubber Hose With Different Types

Name: Zn Series Concrete Vibrator Shaft WireNetted Rubber Hose With Different Types
Brand: YONGTUO
Price: 5 USD

Buy cheap Zn Series Concrete Vibrator Shaft/ Wire-Netted Rubber Hose With Different Types product

Place of Origin : Ningbo,China

Brand Name : YONGTUO

Certification : CE,SGS

Model Number : ZN

MOQ : 10 pcs

Price : $5 per pc

Packaging Details : carton or up to the customers

Delivery Time : about 15 days

Payment Terms : TT or L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 20000 pcs/month

Vibrating Frequency : 220-260HZ

Vibrating Amplitude : 0.7-1.0mm

Length : 1m-12m

dia : 38mm

weight of concrete vibrator shaft : 7 kgs

Overall Dimension : 1376*80*138mm

Contact Now

ZN SERIES CONCRETE VIBRATOR SHAFT/ WIRE-NETTED RUBBER HOSE

Concrete Vibrator Shaft
1Japanese, Dynapac, Chinese type are available;
2Gasoline, Diesel and electrica motor are available.

Concrete Vibrator Shaft

Functional Description:

Apply to compact concrete, make it bind togeter tight and eliminat concrete phenomena such us honeycomb, further increase its strength to ensure the quality of concrete.

Main Features:

1. The tip of vibrator, which forged by high-quality 40 Cr-alloy steel with Salt bath furnace quench technology, mostly improving the mechanical capacity up to hardness of HRC52-58 degree;

2. Leeving: Use 45# carbon steel, handled by high-frenquency quenching and the hardness is up to HRC50~52 degree

3. Rolling element: handled by high-frenquency quench with high grade 40 Cr-alloy steel

4. Flexible pipe: Use high-quality native rubber and 65# Mn alloy spring steel and the thickness around 1.8MM.

Technical Specifications:

			1000 N	50-60 N	40Mn-65Mn	20HRC-30HRC	50-62
JYG16	16mm	9mm						1	75

JYG20
	20mm	10mm						1	80


JYG22	22mm	10mm						2	80

JYG24				60-65 N	20Mn-65Mn		75-80	according to the
	24mm	13mm						demand	100


JYG30	30mm	16mm							120

JYG32
	32mm	18mm							150

JYG36
	36mm	20mm							200

JYG42									250
	42mm	25mm
